3 Pin Right Angle Slide Switch

PCB Mountable Slide Switch Through Hole - 1P2T - Right Angle - 3 pins,Sliding switch is a kind of structure is relatively simple switch, the interior of sliding switch has a slider, sliding switch can be used at power supply cut off with put on, also can be used at recorder conversion guard, widely used in all kinds of radio, recorder, electronic toy telephone, electronic instrument, daily electrical appliances, household electricity.

The "3 Pin Right Angle Slide Switch" is a compact and versatile mechanical switch designed for efficient circuit control in various electronic applications. Its right-angle configuration allows for easy horizontal mounting on printed circuit boards (PCBs), making it particularly useful in situations where vertical space is limited, such as in compact devices like remote controls, audio equipment, and handheld gadgets.

Key Features:

1.3 Pin Configuration:

This switch typically features a 3-pin layout, which allows for either single-pole, single-throw (SPST) or single-pole, double-throw (SPDT) functionality. In SPST mode, the switch can toggle between ON and OFF states, while in SPDT mode, it can switch between two different circuits, providing enhanced versatility in design.

2. Right Angle Design:

The right-angle design of the switch allows it to be mounted parallel to the PCB surface. This is advantageous in compact applications where space is constrained, allowing for easier access and integration into tight layouts.

3. Smooth Sliding Mechanism:

The switch features a reliable sliding mechanism that allows the actuator to be moved smoothly between its positions. This sliding action provides tactile feedback, ensuring users can feel the switch engage, which is crucial in applications requiring frequent operation.

4. Durability:

Constructed from robust materials, the switch is designed to withstand thousands of operational cycles. The housing is typically made from durable plastic, while the metal pins are corrosion-resistant, ensuring long-lasting performance even in demanding environments.

5. Easy Integration:

The 3 Pin Right Angle Slide Switch is designed for easy PCB integration. The pins are optimized for soldering, allowing for straightforward assembly in both manual and automated manufacturing processes. This makes it a popular choice for engineers and designers looking for reliable, space-saving solutions.
