Right Angle PCB Mount LED Tact Switch

Right angle PCB mount LED tact switches are vital components in modern electronics, providing users with tactile feedback and visual indication through integrated LEDs. These switches are designed to be mounted perpendicularly to the printed circuit board (PCB), offering unique advantages in terms of space efficiency and usability. This overview explores the features, applications, benefits, and considerations of right angle PCB mount LED tact switches.

Right angle PCB mount tact switches combine the functionality of a traditional tactile switch with the convenience of a right angle design. Unlike standard switches that mount parallel to the board, right angle switches are positioned at 90 degrees. This orientation allows for better accessibility in tight spaces and can streamline the overall design of electronic devices.

The integrated LED adds a layer of functionality, providing immediate visual feedback about the switch's status—such as indicating whether a device is on or off. This feature enhances user experience by allowing for quick recognition of the device's operational state.

TS20 series compact led-illuminated tact switch comes with high bright LEDs that are able to meet customization requirements. With its reduced space usage on board; the TS20 series LED momentary tact switch is perfect for network infrastructure, automotive and medical applications.

Right Angle Mounting:Designed for mounting at a right angle to the PCB, which saves space and allows for more compact designs.

Illumination:Incorporates LED illumination within the switch, providing visual feedback to the user. Available in various colors, including red, green, blue, yellow, and white. Some models allow for bi-color LED options.

Tactile Feedback:Provides a distinct tactile response when pressed, ensuring the user can feel the activation.Often has a noticeable click or snap action, which enhances the user experience.

Compact Size:Typically small in size, suitable for space-constrained applications.

1. Snap-in type, can be mounted directly on P.C.B Board.

2. It can assembled in different ways:DIP & SMT.

3. Many LED lights are available.

4. It can be mounted with any color and double colors led according to preference.

5. Right Angle type and the P.B.C board become 90 degrees when soldered.
